Adva 3000R7 - Qsfp10;11 G;4 Lr;Sm;Mpo; Overview; Features

QSFP Optical Transceivers
QSFP10/11G/4LR/SM/MPO
Overview 136
Features 136
Specifications 137
Overview
Parameter Value Notes
Sales item number 1061800780-01
Release introduced FSP3000R7 Release
17.1
Fiber Single-mode
Optical connector MPO12, angled
Weight 200 g (7.1 oz)
Temperature range 0 to 70°C (32 to 158°F)
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
Table 70: General Information — QSFP10/11G/4LR/SM/MPO
l Pluggable Transceiver Compatibility
l MTBF Hours for HDEquipment
l Handling Pluggable Transceivers
Features
l Supports one bidirectional optical interface with four optical wavelengths (gray)
l Transports four services through four optical lanes
l Has a separate fiber per optical lane with an MPO12 connector
l Overview
l Specifications
l MTBF Hours for HDEquipment
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 136
