PSM-AC4
PSM-AC4
Overview 97
Features 98
Specifications 98
Overview
The SH4R and SH4R-2 support up to three AC power supply modules (PSM-AC4)
installed at the rear of the shelf.
Figure 34: PSM-AC4 Faceplate
Parameter Value Notes
Sales item number 1040800064-01
Release introduced FSP3000R7 Release 16.2
Compatible shelves
l SH4R
l SH4R-2
Width 108 mm (4.3 in.)
Height 40.8 mm (1.6 in.)
Weight 1.3 kg (2.9 lbs)
Power connector IEC-320-C20 male
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 31: General Information — PSM-AC4
97 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
