PSM-AC6
Recommended external circuit
breaker
l 100 VAC: 17 to 20 A
l 120 VAC: 15 to 16 A
l 240 VAC: 8 to 10 A
Recommended external fuse
l 100 VAC: 20 A
l 120 VAC: 16 A
l 240 VAC: 10 A
Minimum hold-up time 20 ms
AC input type Autoranging
Input frequency 47 to 63 Hz
Active PFC ≥0.97 (pursuant to EN 61000-3-2) - measured
at 100/230 VAC, rated load
Power factor ≥0.97 Conforms to the Ecova 80PLUS®
ENERGY STAR PLATINUM label
Table 40: Electrical Specifications — PSM-AC6
Load 115 VAC 230 VAC
100% load 89% 91%
50% load 92% 94%
20% load 90% 90%
Table 41: Efficiency
The efficiency values meet the requirements of the Ecova 80PLUS® ENERGY STAR
PLATINUM label.
Turn off undervoltage interval 80 to 85 VAC
Turn on undervoltage interval 85 to 90 VAC
Turn off overvoltage set point 290 to 300 VAC
Turn on overvoltage set point 280 to 300 VAC
Alarm set interval (undervoltage) 85 to 90 VAC
Alarm clear interval (undervoltage) ≥90 VAC
Output overvoltage turn off interval 13.6 to 15.0 VDC
Output overcurrent interval 108.0 to 137.0 A
Output overcurrent alarm set point 88.6 A
Output short circuit Hiccup mode
Table 42: Protection
l Power
l AC Power Cable Specifications
l Overview
105 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
