MA-2C5LT
Parameter Value Notes
Sales item number 1063802161-01
Release introduced FSP3000R7 Release 17.1
Compatible shelves and slot
positions
l SH12: Slots 1 - 20
l SH4R:Slots 1 - 7
l SH4R-2:Slots 1 - 7
l SH1R:Slots 1 - 2
Width Single slot
Weight 1.1 kg (2.5 lbs) With pluggable transceiver installed
Modes of operation
l Add/drop multiplexer
(200G)
l Dual muxponder (200G)
l Cross-connect (400G)
No demultiplexing of client ODUks
Power consumption
1
47 W Typical (without pluggable transceivers)
57 W Maximum (without pluggable transceivers)
76 W Typical (includes pluggable transceivers)
89 W Maximum (includes pluggable transceivers)
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 52: General Information — MA-2C5LT
Service Number of services
supported
Mapping Supported on
ports
Number of
lanes
10 GbE 20 ODU2e C1 to C20 1
25 GbE 6 ODUflex C1 to C8 1
40 GbE 5 ODU3 C1 to C20 4
OTU2 20 ODU2 C1 to C20 1
OTU2e 20 ODU2e C1 to C20 1
32 GFC 6 ODUflex C1 to C8 1
Table 53: Supported Services
l Environmental Specifications
l MTBF Hours for HDEquipment
l Traffic Module Compatibility
l Slot Numbers and Assignments — SH12
l Slot Numbers and Assignments — SH4R
l Slot Numbers and Assignments — SH4R-2
l Slot Numbers and Assignments — SH1R
l Pluggable Transceivers
1
When using non-approved pluggable transceivers, the maximum power consumption
alllowed for low-speed client ports (class 4) is 3.5 W and for high-speed client ports (class
117 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
