Guide Rail Kits
Shelf Rack Type Kit Post Distance
Depth Range
Kit Contents Sales Item
Number
SH4R and
SH4R-2
Four-post
l 19-inch
l 23-inch
l ETSI
SA-GUIDE-
SH4-S
400 to 570 mm
(15.7 to 22.4
in.)
l 2 x 19-inch mounting
brackets (L and R)
l 2 x 23-inch mounting
brackets (L and R)
l 2 x ETSImounting brackets
(L and R)
l 4 x ETSI mounting bracket
adapters (2 x FR/RL and 2 x
FL/RR)
l 2 x guide rails (L and R)
l 2 x guide rail brackets for
23-inch rack (L and R)
l 20 x M6x20 screws
l 2 x M6 cage nuts
l 8 x M4x6 screws
l 8 x M3x6 screws
1013800062-02
SA-GUIDE-
SH4-L
570 to 800 mm
(22.4 to 31.5
in.)
1013800064-02
Two-post
l ETSI
SA-GUIDE-
SH4-ETSI2
N/A
l 2 x ETSImounting brackets
(L and R)
l 2 x guide rail brackets (L
and R)
l 8 x M4x6 screws
l 8 x M6x20 screws
l 2 x M6 cage nuts
1013800072-01
SH1R Four-post
l 19-inch
l 23-inch
l ETSI
SA-GUIDE-
SH1-S
400 to 534 mm
(15.7 to 21.1
in.)
l 4 x 23-inch mounting
brackets (L and R)
l 4 x ETSImounting brackets
(L and R)
l 2 x guide rails (L and R)
l 10 M6x12 screws
1013800067-01
SA-GUIDE-
SH1-L
534 to 800 mm
(21.1 to 31.5
in.)
1013800068-01
EQUIPMENT DAMAGE MAY RESULT IF AN SH4R OR SH4R-2
IS INSTALLED IN A TWO-POST NON-ETSI RACK.
The depth and weight of a populated shelf might cause structural and
mounting bracket damage. Additionally, its instability might cause it
to fall and become damaged. For non-ETSI configurations, you must
install the SH4R or SH4R-2in a four-post rack (with the guide rail kit).
EQUIPMENT DAMAGE MAY RESULT IF AN SH1R IS
INSTALLED IN A TWO-POST RACK (WITHOUT THE MID-
MOUNT BRACKETS).
The depth and weight of a populated shelf might cause structural and
mounting bracket damage. Additionally, its instability might cause it
to fall and become damaged.
