Clearance Requirements
Figure 53: SH12 — Single Rack Installation
With side air covers closed, a minimum of 15 cm (5.9 in.) recommended
at the rear of the shelf
With side air covers open, a minimum of 1 cm (0.39 in.) recommended at
the rear of the shelf but the temperature range is limited to 45°C (113°F).
199 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
