Installing Side Air Covers
Figure 81: Side Air Cover Installed
6. Repeat Steps 2 through 5 for the air vent on the bottom of this side.
7. Repeat Steps 2 through 6 for the opposite side of the shelf.
l Installation Overview — SH12 Shelf
l Clearance Requirements
l Side Air Covers
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 272
