Overview
Figure 87: SH4R and SH4R-2 Grounding Terminals Location
Figure 88: SH1R Grounding Terminal Location
The signal ground is currently not supported.
l Grounding — SH12
l Grounding — SH4R
l Grounding — SH4R-2
l Grounding — SH1R
279 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
