SH12 Shelf
Figure 2: SH12 Shelf and Components (HW Rev. 2.0 version)
The difference between SH12 HW Rev. 1.0 version and the SH12 HW
Rev. 2.0 version is the type of DC power connectors on the shelf front.
The preceding figure shows the SH12 with DC PSMs installed. The
SH12 also supports AC PSMs.
Parameter Value Notes
Sales item number 1078800021-02 HW Rev. 2.0 version (introduced
in Release 1.3.1)
1078800021-01 HW Rev. 1.0 version (introduced
in Release 1.1.1)
Release introduced FSP3000R7 Release 16.2
Depth 280 mm (11.0 in.) With front covers
Width 443 mm (17.5 in.)
Height
l 12U
l 533 mm (21.0 in.)
Table 2: General Information — SH12
