Installing a QSFPPluggable Transceiver
When you apply power to the system in a later chapter, the
ADVAequipment automatically provisions.
Figure 97: Inserting a QSFPPluggable Transceiver
Do not remove the dust plug from the QSFP pluggable transceiver at
this time. It will be removed when you connect the optical cables.
l Electrostatic Discharge Damage Prevention and Warning
l Pluggable Transceivers
l QSFP Optical Transceivers
l Handling Pluggable Transceivers
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 314
