SH12 Shelf
Parameter Value Notes
1+1 (redundant) power configuration
l 1304 W @100 to 240 VAC
l 13.0 A @100 VAC
l 10.9 A @120 VAC
l 5.3 A @240 VAC
2+1 (redundant) power configuration
l 2637 W @100 to 240 VAC
l 26.4 A @ 100 VAC
l 22.0 A @120 VAC
l 10.8 A @ 240 VAC
3+1 (redundant) power configuration
l 3956 W@ 100 to 240 VAC
l 39.6 A @100 VAC
l 33.0 A@120 VAC
l 16.1 A @ 240 VAC
Maximum internal power
l 1+0 and 1+1: 1200 W
l 2+0 and 2+1: 2400 W
l 3+0 and 3+1: 3600 W
PSM-DC
l 1+0 and 1+1:1200 W
l 2+0 and 2+1: 2400 W
l 3+0 and 3+1: 3600 W
PSM-AC6
Environmental standards
compliance
l Telcordia SR-3580 Level 3
(NEBS)
l ETSI EN 300 019-1-3 Class
3.1
l IEC 60529 IP20 (indoor office)
Table 2: General Information — SH12
Slot numbers and identifiers are printed on the front of the shelf.
l Environmental Specifications
l Power
l MTBF Hours for HDEquipment
l Infrastructure Modules
l Traffic Module Compatibility
l Accessories
l Installation Overview — SH12 Shelf
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 32
