Connecting ACPower to theSH12 Shelf
For system cooling, you must install an appropriate slot cover in the
empty PSM slots.
4. Based on your configuration, identify the PSM that will be connected first.
5. For North America and Japan installations, verify that the ACpower cord is equipped
with a snap-on ferrite.
6. Insert the AC power coupler into the receptacle on the PSM.
7. Secure the power cable with the cord clip.
8. Insert theACpower cable plug into the dedicated ACpower source outlet.
The ACpower cable plug serves as the main disconnection device.
Therefore, the dedicated AC power outlet must remain accessible so as
to be readily operable for use.
9. Repeat this procedure for each power cable needed for your configuration.
10. If the dedicated AC power source outlet has a power switch, set it to the ON (|)
position to power on the system for the first time.
As soon as power is up, the ECM-2 starts booting. The Mod LED of the first PSM
should turn green to indicate that the units are functioning properly.
The FTM-2s should start working, one after another and the Svc LED should turn
green. This also indicates that the FTMs are functioning properly. In addition, the
Mod LEDs of all modules installed in the shelf should turn green.
If the Mod LED of the PSM is off, no power is being supplied to the unit. In
case of an error, the Mod LED turns red. For troubleshooting information,
see Troubleshooting with Component LEDs or contact ADVA Optical
Networking for technical assistance.
