Replacing a PSM
To remove the module:
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. If installed, remove the front cover from the shelf as described in Removing and
Installing Front Covers.
3. Use a Torx T10 screwdriver to unscrew the retaining screw from the PSM-DC.
4. Grasp the handle, and then slowly slide the PSM-DC out of the shelf until the Mod
LEDis unlit.
5. Continue to remove the PSM-DC completely from the shelf.
6. Place the defective PSM-DC on a static-dissipative mat.
7. Return the defective PSM-DC to ADVA Optical Networkingas described in
Returning Equipment
To install the new module:
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. Hold the replacement PSM-DC upright with the faceplate toward you.
3. Insert the PSM into the appropriate slot.
4. Gently apply pressure to the faceplate while you push the module into the slot.
5. Push on the faceplate to fully seat the module. The module is completely inserted
when its faceplate is flush with the faceplates of the adjacent modules and the shelf
panels.
6. After you have completely inserted the PSM, hand-tighten the thumb screws to
prevent inadvertent dislodging.
7. Use a Torx T10 screwdriver to gently tighten the retaining screw as needed. Do not
overtighten.
8. The Mod LED of the PSM-DC should turn green to indicate that the units are
functioning properly.
9. Reinstall the front cover as described in Removing and Installing Front Covers.
If the Mod LED of the PSM-DC is off, no power is being supplied to the
unit. In case of an error, the power LED turns red. For troubleshooting
information, see Troubleshooting with Component LEDs or contact
ADVA Optical Networking for technical assistance.
l Electrostatic Discharge Damage Prevention and Warning
l PSM-DC
l Handling Modules
l DCPower Source Requirements
l Electrical Safety Guidelines and Warnings
l In Case of Electrical Accident
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 426
