SH4R-2 Shelf
Figure 12: SH4R-2 Shelf and Components — Rear View
The preceding figure shows the SH4R-2 with AC PSMs installed. The
SH4R-2 also supports DC PSMs.
Parameter Value Notes
Sales item number 1078800052-01
Release introduced FSP3000R7 Release 16.2
Depth 542 mm (21.5 in.) With front cover and rear power
cables
Width 443 mm (17.5 in.)
Height
l 4U
l 177.8 mm (7.0 in.)
Weight 22.6 kg (49.9 lbs) Weight includes:
l Two FTM-4s
l One CEM-4
l Two ECM-2s
l Three PSMs
l Front cover
l Slot covers
Table 8: General Information — SH4R-2
53 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
