ECM-2
Figure 28: ECM-2 Faceplate
The HD Subshelf configuration does not use the USB, CLI, External
DCN, and shelf interconnect ports. You must perform all management
tasks through the NCUinterface.
Parameter Value Notes
Sales item number 1063801012-01
Release introduced FSP3000R7 Release 16.2
Compatible shelves
l SH12
l SH4R
l SH4R-2
Width 119.8 mm (4.7 in.)
Height 21.5 mm (0.9 in.)
Weight 0.4 kg (0.8 lbs)
Power consumption 16 W Typical
19 W Maximum
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 22: General Information — ECM-2
To prevent airflow shortcut, you must reinsert or replace the ECM-2
within one minute.
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 84
