DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

1014

Example

Show trap source IP interface:

DGS-3120-24TC:admin# show trap source_ip

Command: show trap source_ip

Trap Source IP Interface Configuration:

IP Interface : System

IPv4 Address : None

DGS-3120-24TC:admin#
