D-Link xStack DGS-3120 Series - Chapter 19 Connectivity Fault Management (CFM) Command List (RI and EI Mode Only)

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
200
Chapter 19 Connectivity Fault
Management (CFM)
Command List (RI and EI
Mode Only)
create cfm md <string 22> {md_index <uint 1-4294967295>} level <int 0-7>
config cfm md [<string 22> | md_index <uint 1-4294967295>] {mip [none | auto | explicit] |
sender_id [none | chassis | manage | chassis_manage]}
create cfm ma <string 22> {ma_index <uint 1-4294967295>} md [<string 22> | md_index <uint 1-
4294967295>]
config cfm ma [<string 22> | ma_index <uint 1-4294967295>] md [<string 22> | md_index <uint 1-
4294967295>] {vlanid <vlanid 1-4094> | mip [none | auto | explicit | defer] | sender_id [none |
chassis | manage | chassis_manage | defer] | ccm_interval [100ms | 1sec | 10sec | 1min |
10min] | mepid_list [add | delete] <mepid_list1-8191>}
create cfm mep <string 32> mepid <int 1-8191> md [<string 22> | md_index <uint 1-
4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>] direction [inward | outward]
port <port>
config cfm mep [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index <uint 1-
4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {state [enable | disable] |
ccm [enable | disable] | pdu_priority <int 0-7> | fault_alarm [all | mac_status | remote_ccm |
error_ccm | xcon_ccm | none] | alarm_time <centisecond 250 -1000> | alarm_reset_time
<centisecond 250-1000>}
delete cfm mep [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index <uint 1-
4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]]
delete cfm ma [<string 22> | ma_index <uint 1-4294967295>] md [<string 22> | md_index <uint 1-
4294967295>]
delete cfm md [<string 22> | md_index <uint 1-4294967295>]
enable cfm
disable cfm
config cfm ports <portlist> state [enable | disable]
show cfm ports <portlist>
show cfm {[md [<string 22> | md_index <uint 1-4294967295>] {ma [<string 22> | ma_index <uint
1-4294967295>] {mepid <int 1-8191>}} | mepname <string 32>]}
show cfm fault {md [<string 22> | md_index <uint 1-4294967295>] {ma [<string 22> | ma_index
<uint 1-4294967295>]}}
show cfm port <port> {level <int 0-7> | direction [inward | outward] | vlanid <vlanid 1-4094>}
cfm loopback <macaddr> [mepname <string 32> | mepid <int 1-8191> md [<string 22> |
md_index <uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {num
<int 1-65535> | [length <int 0-1500> | pattern <string 1500>] | pdu_priority <int 0-7>}
cfm linktrace <macaddr> [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index
<uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {ttl <int 2-255> |
pdu_priority <int 0-7>}
show cfm linktrace [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index <uint
1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {trans_id <uint>}
delete cfm linktrace {[md [<string 22> | md_index <uint 1-4294967295>] {ma [<string 22> |
ma_index <uint 1-4294967295>] {mepid <int 1-8191>}} | mepname <string 32>]}
show cfm mipccm
config cfm mp_ltr_all [enable | disable]
show cfm mp_ltr_all
show cfm remote_mep [mepname <string 32> | md [<string 22> | md_index <uint 1-
4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>] mepid <int 1-8191>]
