D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1030
Chapter 109 TFTP Client Command List
download [firmware_fromTFTP [<ipaddr> | <ipv6addr> | <domain_name 255>] src_file
<path_filename 64> {[unit <unit_id> | all]} {dest_file <pathname>} {boot_up} | cfg_fromTFTP
[<ipaddr> | <ipv6addr> | <domain_name 255>] src_file <path_filename 64> {[unit <unit_id> |
all]} {[increment | dest_file <pathname>]}]
upload [cfg_toTFTP [<ipaddr> | <ipv6addr> | <domain_name 255>] dest_file <path_filename 64>
{unit <unit_id>} {src_file <pathname>} {[include | exclude | begin] <filter_string 80>
{<filter_string 80> {<filter_string 80>}} {[include | exclude | begin] <filter_string 80>
{<filter_string 80> {<filter_string 80>}} {[include | exclude | begin] <filter_string 80>
{<filter_string 80> {<filter_string 80>}}}}} | log_toTFTP [<ipaddr> | <ipv6addr> |
<domain_name 255>] dest_file <path_filename 64> | attack_log_toTFTP [<ipaddr> |
<ipv6addr> | <domain_name 255>] dest_file <path_filename 64> {unit <unit_id>} |
firmware_toTFTP [<ipaddr> | <ipv6addr> | <domain_name 255>] dest_file <path_filename
64> {unit <unit_id>} {src_file <pathname>}]
109-1 download
Description
This command is used to download the firmware image and configuration from TFTP server.
Format
download [firmware_fromTFTP [<ipaddr> | <ipv6addr> | <domain_name 255>] src_file
<path_filename 64> {[unit <unit_id> | all]} {dest_file <pathname>} {boot_up} | cfg_fromTFTP
[<ipaddr> | <ipv6addr> | <domain_name 255>] src_file <path_filename 64> {[unit <unit_id> |
all]} {[increment | dest_file <pathname>]}]
Parameters
firmware_fromTFTP – Specify to download firmware from a TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
src_file - (Optional) Used to identify the parameter “path_filename”.
<path_filename 64> - Enter the source file path name here. This name can be up to 64
characters long.
unit - (Optional) Specify which unit on the stacking system. If it is not specified, it refers to the
master unit.
<unit_id> - Enter the unit ID value. This value must be between 1 and 6.
all - When all is specified, the firmware image on all units will be updated.
dest_file - (Optional) Used to identify the parameter “path_filename”.
<pathname> - Enter the destination file path name here.
boot_up - (Optional) Specify as boot up file.
cfg_fromTFTP – Specify to download a configuration file from a TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
src_file - (Optional) Used to identify the parameter “path_filename”.
<path_filename 64> - The pathname specifies the pathname on the TFTP server. It can
be a relative pathname or an absolute pathname. This name can be up to 64 characters
long.
