D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1108
Chapter 121 Weighted Random Early
Detection (WRED)
Command List
enable wred
disable wred
create wred profile <int 2-128> profile_name <profile_name 32>
config wred profile [default | profile_id <int 2-128> | <profile_name 32>] {tcp | non_tcp} {green |
yellow | red} min_threshold <int 0-100> max_threshold <int 0-100> max_drop_rate <int 0-
100>
config wred ports [<portlist> | all] [cos <class_id 0-7> [profile [default | profile_id <int 2-128> |
<profile_name 32>] | weight <int 0-15>] | profile [default | profile_id <int 2-128> |
<profile_name 32>] | weight <int 0-15>]
delete wred profile [profile_id <int 2-128> | <profile_name 32> |all]
show wred {ports {<portlist>}}
show wred profile {[ default | profile_id <int 2-128> | <profile_name 32>]}
121-1 enable wred
Description
This command is used to enable the WRED global state.
Format
enable wred
Parameters
None.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable global wred state:
DGS-3120-24TC:admin#enable wred
Command: enable wred
Success.
DGS-3120-24TC:admin#
