D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
28
Parameters
<portlist> - A range of ports for which you want ingress checking. The port list is specified by
listing the lowest switch number and the beginning port number on that switch, separated by a
colon. Then highest switch number, and the highest port number of the range (also separated
by a colon) are specified. The beginning and end of the port list range are separated by a
dash. For example, 1:3 would specify switch number 1, port 3. 2:4 specifies switch number 2,
port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 − in
numerical order.
all - Specify that all the port will be used for this configuration.
gvrp_state - (Optional) Enabled or disables GVRP for the ports specified in the port list.
enable - Specify that GVRP for the specified ports will be enabled.
disable - Specify that GVRP for the specified ports will be disabled.
ingress_checking - (Optional) Enables or disables ingress checking for the specified portlist.
enable - Specify that ingress checking will be enabled for the specified portlist.
disable - Specify that ingress checking will be disabled for the specified portlist.
acceptable_frame - (Optional) The type of frame will be accepted by the port. There are two
types:
tagged_only - Only tagged packets can be accepted by this port.
admit_all - All packets can be accepted.
pvid - (Optional) Specify the PVID of the ports.
<vlanid 1-4094> - Enter the VLAN ID here. The VLAN ID value must be between 1 and 4094.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To sets the ingress checking status, the sending and receiving GVRP information:
DGS-3120-24TC:admin# config port_vlan 1:1-1:5 gvrp_state enable
ingress_checking enable acceptable_frame tagged_only pvid 2
Command: config port_vlan 1:1-1:5 gvrp_state enable ingress_checking enable
acceptable_frame tagged_only pvid 2
Success
DGS-3120-24TC:admin#
3-8 show vlan
Description
This command is used to display the vlan information including of parameters setting and
operational value.
Format
show vlan {<vlan_name 32>}
Parameters
<vlan_name 32> - (Optional) Enter the VLAN name to be displayed. The VLAN name can be up
to 32 characters long.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
