D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1132
Appendix C Trap Log Entries
This table lists the trap logs found on DGS-3120 Series Switch.
Log Entry Description OID
swL2macNotification This trap indicate the MAC addresses
variation in the address table .
Binding 1: swL2macNotifyInfo
1.3.6.1.4.1.171.11.117.2.1.2.100.1.
2.0.1(DGS-3120-24TC)
1.3.6.1.4.1.171.11.117.3.1.2.100.1.
2.0.1(DGS-3120-24PC)
1.3.6.1.4.1.171.11.117.4.1.2.100.1.
2.0.1(DGS-3120-24SC)
1.3.6.1.4.1.171.11.117.5.1.2.100.1.
2.0.1(DGS-3120-48TC)
1.3.6.1.4.1.171.11.117.6.1.2.100.1.
2.0.1(DGS-3120-48PC)
1.3.6.1.4.1.171.11.117.7.1.2.100.1.
2.0.1(DGS-3120-24SC-DC)
swL2PortSecurityViolationTrap
When the port_security trap is enabled, if
there's a new MAC that violates the pre-
defined port security configuration, a trap will
be sent out.
Binding 1: swL2PortSecurityPortIndex
2: swL2PortSecurityViolationMac
1.3.6.1.4.1.171.11.117.2.1.2.100.1.
2.0.2(DGS-3120-24TC)
1.3.6.1.4.1.171.11.117.3.1.2.100.1.
2.0.2(DGS-3120-24PC)
1.3.6.1.4.1.171.11.117.4.1.2.100.1.
2.0.2(DGS-3120-24SC)
1.3.6.1.4.1.171.11.117.5.1.2.100.1.
2.0.2(DGS-3120-48TC)
1.3.6.1.4.1.171.11.117.6.1.2.100.1.
2.0.2(DGS-3120-48PC)
1.3.6.1.4.1.171.11.117.7.1.2.100.1.
2.0.2(DGS-3120-24SC-DC)
swIpMacBindingViolationTrap
When the IP-MAC Binding trap is enabled, if
there's a new MAC that violates
the pre-defined port security configuration, a
trap will be sent out.
Binding 1: swIpMacBindingPortIndex
2: swIpMacBindingViolationIP
3: swIpMacBindingViolationMac
1.3.6.1.4.1.171.12.23.5.0.1
swIpMacBindingIPv6ViolationTrap
When the IP-MAC Binding trap is enabled, if
there's a new MAC that violates the pre-
defined IPv6 IMPB configuration, a trap will
be sent out.
Binding objects:
(1) swIpMacBindingPortIndex
(2) swIpMacBindingViolationIPv6Addr
(3) swIpMacBindingViolationMac
1.3.6.1.4.1.171.12.23.5.0.4
swIpMacBindingShutdownTrap
When the rate limiting is shutdown mode and
the DHCP rate excludes the limiting, a trap
will be sent out.
Binding objects:
(1). swIpMacBindingPortIndex
1.3.6.1.4.1.171.12.23.5.0.5
swIpMacBindingRecoveryTrap
When the port is shutdown by DHCP rate
limiting and the auto-recovery timer is
timeout, a trap will be sent out.
Binding objects:
(1). swIpMacBindingPortIndex
1.3.6.1.4.1.171.12.23.5.0.6
swFilterDHCPv6ServerDetectedTrap
Send trap when an illegal DHCPv6 server is
detected.
Binding objects:
(1) swFilterDetectedIPv6
(2) swFilterDetectedport
1.3.6.1.4.1.171.12.37.100.0.2
swFilterICMPv6RaAllNodesDetectedTrap
Send trap when an illegal ICMPv6 all-nodes
RA is detected.
Binding objects:
(1) swFilterDetectedIPv6
(2) swFilterDetectedport
1.3.6.1.4.1.171.12.37.100.0.3
swPktStormOccurred
The trap is sent when packet storm is
1.3.6.1.4.1.171.12.25.5.0.1

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
