D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
659
Chapter 65 Multicast Filter Command
List
create mcast_filter_profile {[ipv4 | ipv6]} profile_id <value 1-24> profile_name <name 32>
config mcast_filter_profile [profile_id <value 1-24> | profile_name <name 32>] {profile_name
<name 32> | [add | delete] <mcast_address_list>}(1)
config mcast_filter_profile ipv6 [profile_id <value 1-24> | profile_name <name 32>]
{profile_name <name 32> | [add | delete] <mcastv6_address_list>}(1)
delete mcast_filter_profile {[ipv4 | ipv6]} [profile_id [<value 1-24> | all] | profile_name <name 32>]
show mcast_filter_profile {[ipv4 | ipv6]} {[profile_id <value 1-24> | profile_name <name 32>]}
config limited_multicast_addr [ports <portlist> | vlanid <vlanid_list>] {[ipv4 | ipv6]} {[add
[profile_id <value 1-24> | profile_name <name 32>] | delete [profile_id <value 1-24> |
profile_name <name 32> | all]] | access [permit | deny]}(1)
config max_mcast_group [ports <portlist> | vlanid <vlanid_list] {[ipv4 | ipv6]} {max_group [<value
1-1024> | infinite] | action [ drop | replace]}(1)
show max_mcast_group [ports {<portlist>} | vlanid {<vlanid_list >}] {[ipv4 | ipv6]}
show limited_multicast_addr [ports {<portlist>} | vlanid {<vlanid_list>}] {[ipv4 | ipv6]}
config cpu_filter l3_control_pkt <portlist> [{dvmrp | pim | igmp_query} | all] state [enable |
disable]
show cpu_filter l3_control_pkt ports {<portlist>}
65-1 create mcast_filter_profile
Description
This command is used to configure a multicast address profile. Multiple ranges of multicast
addresses can be defined in the profile. If the IPv4 or ipv6 option is not specified, IPv4 is implied.
Format
create mcast_filter_profile {[ipv4 | ipv6]} profile_id <value 1-24> profile_name <name 32>
Parameters
ipv4 - (Optional) Adds an IPv4 multicast profile.
ipv6 - (Optional) Adds an IPv6 multicast profile.
profile_id - The ID of the profile.
<value 1-24> - Enter the profile ID value . This value must be between 1 and 24.
profile_name - Provides a meaningful description for the profile.
<name 32> - Enter the profile name . The profile name can be up to 32 characters long.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create a multicast address profile with a profile ID of 2 and a profile name of MOD:
