D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
840
84-6 config scheduling_mechanism
Description
This command is used to configure the traffic scheduling mechanism for each CoS queue.
Format
config scheduling_mechanism {ports [<portlist> | all]} [strict | wrr]
Parameters
ports - (Optional) Specify a range of ports to be configured.
<portlist> - Enter the list of port used for this configuration here.
all - For set all ports in the system, you may use “all” parameter. If no parameter is specified,
system will set all ports.
strict - All queues operate in strict mode.
wrr - Each queue operates based on its setting.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the traffic scheduling mechanism for each CoS queue:
DGS-3120-24TC:admin# config scheduling_mechanism strict
Command: config scheduling_mechanism strict
Success.
DGS-3120-24TC:admin#
To configure the traffic scheduling mechanism for CoS queue on port 1:1:
DGS-3120-24TC:admin# config scheduling_mechanism ports 1:1 strict
Command: config scheduling_mechanism ports 1:1 strict
Success.
DGS-3120-24TC:admin#
84-7 show scheduling
Description
This command is used to display the current traffic scheduling parameters.
Format
show scheduling {<portlist>}

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
