xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
205
Format
create cfm mep <string 32> mepid <int 1-8191> md [<string 22> | md_index <uint 1-
4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>] direction [inward | outward]
port <port>
Parameters
<string 32> - Enter the MEP name used. It is unique among all MEPs configured on the
device.This name can be up to 32 characters long.
mepid - Specify the MEP ID. It should be configured in the MA’s MEPID list.
<int 1-8191> - Enter the MEP ID used here. This value must be between 1 and 8191.
md - Specify the maintenance domain name.
<string 22> - Enter the maintenance domain name used here. This name can be up to 22
characters long.
md_index - Specify the maintenance domain index.
<uint 1-4294967295> - Enter the maintenance domain index value here. This value must
be between 1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name used here. This name can be up to 22
characters long.
ma_index - Specify the maintenance association index.
<uint 1-4294967295> - Enter the maintenance association index value here. This value
must be between 1 and 4294967295.
direction - This is the MEP direction.
inward - Specify the inward facing (up) MEP.
outward - Specify the outward facing (down) MEP.
port - Specify the port number. This port should be a member of the MA’s associated VLAN.
<port> - Enter the port number used here.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create a CFM MEP:
DGS-3120-24TC:admin#create cfm mep mep1 mepid 1 md op_domain ma op1 direction
inward port 2
Command: create cfm mep mep1 mepid 1 md op_domain ma op1 direction inward port
1:2
Success.
19-6 config cfm mep
Description
This command is used to configure the parameters of an MEP.
An MEP may generate 5 types of Fault Alarms, as shown below by their priorities from high to low:
• Cross-connect CCM Received: priority 5
