D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
563
53-8 show lldp mgt_addr
Description
This command is used to display the LLDP management address information.
Format
show lldp mgt_addr {[ipv4 {<ipaddr>} | ipv6 {<ipv6addr>}]}
Parameters
ipv4 - (Optional) Specify the IPv4 address used for the display.
<ipaddr> - (Optional) Enter the IPv4 address used for this configuration here.
ipv6 - (Optional) Specify the IPv6 address used for the display.
<ipv6addr> - (Optional) Enter the IPv6 address used for this configuration here.
Restrictions
None.
Example
To display management address information:
DGS-3120-24TC:admin# show lldp mgt_addr ipv4 192.168.254.10
Command: show lldp mgt_addr ipv4 192.168.254.10
Address 1
-----------------------------------------------------------------------
Subtype : IPV4
Address : 192.168.254.10
IF type : unknown
OID : 1.3.6.1.4.1.171.10.36.1.11
Advertising ports :
1:1-1:5, 1:7, 2:10-2:20
DGS-3120-24TC:admin#
53-9 show lldp ports
Description
This command is used to display the LLDP per port configuration for advertisement options.
Format
show lldp ports {<portlist>}
Parameters
<portlist> - (Optional) Specify a range of ports to be displayed.
If the port list is not specified, information for all the ports will be displayed.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
