D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
978
101-21 config snmp engineID
Description
This command is used to configure a identifier for the SNMP engine on the Switch.
Format
config snmp engineID <snmp_engineID 10-64>
Parameters
engineID - Identify for the SNMP engine on the Switch. It is octet string type. It accepts the hex
number directly.
<snmp_engineID 10-64> - Enter the SNMP engine ID here. This value must be between 10
and 64.
Restrictions
Only Administrator-level users can issue this command.
Example
To configure SNMP engine ID to “1023457890”:
DGS-3120-24TC:admin# config snmp engineID 1023457890
Command: config snmp engineID 1023457890
Success.
DGS-3120-24TC:admin#
101-22 show snmp engineID
Description
The show snmp engineID command displays the identification of the SNMP engine on the Switch.
The default value is suggested in RFC2271. The very first bit is 1, and the first four octets are set
to the binary equivalent of the agent’s SNMP management private enterprise number as assigned
by IANA, D_Link is 171. The fifth octet is 03 to indicates the rest is the MAC address of this device.
The 6th –11th octets is MAC address.
Format
show snmp engineID
Parameters
None.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
