D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
214
Port : 1:2
Direction : Inward
CFM Port Status : Enabled
MAC Address : 00-01-02-03-04-02
MEP State : Enabled
CCM State : Enabled
PDU Priority : 7
Fault Alarm : Disabled
Alarm Time : 250 centisecond((1/100)s)
Alarm Reset Time : 1000 centisecond((1/100)s)
Highest Fault : Some Remote MEP Down
AIS State : Disabled
AIS Period : 1 Second
AIS Client Level : Invalid
AIS Status : Not Detected
LCK State : Disabled
LCK Period : 1 Second
LCK Client Level : Invalid
LCK Status : Not Detected
Out-of-Sequence CCMs: 0 received
Cross-connect CCMs : 0 received
Error CCMs : 0 received
Normal CCMs : 0 received
Port Status CCMs : 0 received
If Status CCMs : 0 received
CCMs transmitted : 71
In-order LBRs : 0 received
Out-of-order LBRs : 0 received
Next LTM Trans ID : 0
Unexpected LTRs : 0 received
LBMs Transmitted : 0
AIS PDUs : 0 received
AIS PDUs Transmitted: 0
LCK PDUs : 0 received
LCK PDUs Transmitted: 0
Remote
MEPID MAC Address Status RDI PortSt IfSt LCK Detect Time
------ ----------------- ------ --- ------- ---------- --- -------------------
2 FF-FF-FF-FF-FF-FF FAILED No No No No 2011-07-13 12:00:00
DGS-3120-24TC:admin#
19-15 show cfm fault
Description
This command is used to display all the fault conditions detected by the MEPs contained in the
specified MA or MD. This display provides the overview of the fault status by MEPs.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
