D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
827
Chapter 83 QinQ Command List (RI and
EI Mode Only)
enable qinq
disable qinq
config qinq inner_tpid <hex 0x1-0xffff>
config qinq ports [<portlist> | all] {role [uni | nni] | missdrop [enable | disable] | outer_tpid <hex
0x1 - 0xffff> | use_inner_priority [enable | disable] | add_inner_tag [<hex 0x1 - 0xffff> |
disable]}
show qinq
show qinq inner_tpid
show qinq ports {<portlist>}
create vlan_translation ports [<portlist> | all] [add cvid <vidlist> | replace cvid <vlanid 1-4094>]
svid <vlanid 1-4094> {priority <priority 0-7>}
delete vlan_translation ports [<portlist> | all] {cvid <vidlist>}
show vlan_translation {[ports <portlist> | cvid <vidlist>]}
83-1 enable qinq
Description
This command is used to enable QinQ. When QinQ is enabled, all network port roles will be NNI
ports; all existing static VLANs will run as S-VLAN; all dynamic learned L2 address will be cleared;
all dynamic registered VLAN entries will be cleared; and GVRP will be disabled.
To run GVRP on the Switch, the administrator should enable GVRP manually. In QinQ mode,
GVRP protocol will employ reserve address 01-80-C2-00-00-0D.
Format
enable qinq
Parameters
None.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable QinQ:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
