D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
835
Chapter 84 Quality of Service (QoS)
Command List
config bandwidth_control [<portlist> | all] {rx_rate [no_limit | <value 8-10240000>] | tx_rate
[no_limit | <value 8-10240000>]}
show bandwidth_control {<portlist>}
config per_queue bandwidth_control {ports [<portlist> | all ]} <cos_id_list> {{min_rate [no_limit |
<value 8-10240000>]} max_rate [no_limit | <value 8-10240000>]}
show per_queue bandwidth_control {<portlist>}
config scheduling {ports [<portlist> | all]} <class_id 0-7> [strict | weight <value 1-127>]
config scheduling_mechanism {ports [<portlist> | all]} [strict | wrr]
show scheduling {<portlist>}
show scheduling_mechanism {<portlist>}
config 802.1p user_priority <priority 0-7> <class_id 0-7>
show 802.1p user_priority
config 802.1p default_priority [<portlist> | all] <priority 0-7>
show 802.1p default_priority {<portlist>}
enable hol_prevention
disable hol_prevention
show hol_prevention
config dscp trust [<portlist> | all] state [enable | disable]
show dscp trust {<portlist>}
config dscp map {[<portlist> | all]} [dscp_priority <dscp_list> to <priority 0-7> | dscp_dscp
<dscp_list> to <dscp 0-63>]
show dscp map {<portlist>} [dscp_priority | dscp_dscp] {dscp <dscp_list>}
84-1 config bandwidth_control
Description
This command is used to configure the port bandwidth limit control.
Format
config bandwidth_control [<portlist> | all] {rx_rate [no_limit | <value 8-10240000>] | tx_rate
[no_limit | <value 8-10240000>]}
Parameters
<portlist> - Specify a range of ports to be configured.
all – Specify that all the ports will be used for this configuration.
rx_rate - (Optional) Specify the limitation applied to receive data rate.
no_limit - Indicates there is no limit on receiving bandwidth of the configured ports. An integer
value from m to n sets a maximum limit in Kbits/sec. The actual bandwidth will be an
adjusted value based on the user specified bandwidth. The actual limit may be equal to the
user specified limit, but will not exceed it. The actual limit recognized by the device, will be
displayed when the command is executed.
<value 8-10240000> - Enter the receiving data rate here. This value must be between 8 and
10240000.
tx_rate - (Optional) Specify the limitation applied to transmit data rate.
no_limit - Indicates there is no limit on port tx bandwidth. An integer value from m to n sets a

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
