Page #58 background image
xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
53
Parameters
enable - Specify to enable the sending of 802.1X traps.
disable - Specify to disable the sending of 802.1X traps.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
This example shows how to enable the trap state for 802.1X.
DGS-3120-24TC:admin# config 802.1x trap state enable
Command: config 802.1x trap state enable
Success.
DGS-3120-24TC:admin#
4-22 config radius add
Description
This command is used to add a new RADIUS server. The server with lower index has higher
authenticative priority.
Format
config radius add <server_index 1-3> [<server_ip> | <ipv6addr>] [key <password 32> |
encryption_key <password 56>] [default | {auth_port <udp_port_number 1-65535 > |
acct_port <udp_port_number 1-65535 > | timeout <sec 1-255> | retransmit<int 1-20>}(1)]
Parameters
<server_index 1-3> - Enter the RADIUS server index. This value must be between 1 and 3.
<server_ip> - Enter the IP address of the RADIUS server here.
<ipv6addr> - Enter the IPv6 address of the RADIUS server here.
key - The key pre-negotiated between switch and the RADIUS server. It is used to encrypt user’s
authentication data before being transmitted over internet. The maximum length of the key is
32.
<password 32> - Enter the password here. The password can be up to 32 characters long.
encryption_key - The key pre-negotiated between the Switch and the RADIUS server. It is used
to encrypt user’s authentication data before being transmitted over the Internet. The maximum
length of the key is 32.
<password 56> - The encrypted key string. The maximum length of the plain text key is 56
bytes. The encryption algorithm is based on DES.
default - Sets the authentication UDP port number to 1812 accounting UDP port number to 1813,
timeout to 5 seconds and retransmit to 2.
auth_port - Specify the UDP port number which is used to transmit RADIUS authentication data
between the Switch and the RADIUS server. The range is 1 to 65535.
<udp_port_number 1-65535> - Enter the authentication port number here. This value must
be between 1 and 65535.
acct_port - Specify the UDP port number which is used to transmit RADIUS accounting statistics
between the Switch and the RADIUS server. The range is 1 to 65535.
