D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
142
Chapter 8 Address Resolution
Protocol (ARP) Command
List
create arpentry <ipaddr> <macaddr>
delete arpentry [<ipaddr> | all]
config arpentry <ipaddr> <macaddr>
config arp_aging time <min 0-65535>
clear arptable
show arpentry {ipif <ipif_name 12> | ipaddress <ipaddr> | static | mac_address <macaddr>}
8-1 create arpentry
Description
This command is used to enter a static ARP entry into the Switch’s ARP table.
Format
create arpentry <ipaddr> <macaddr>
Parameters
<ipaddr> - The IP address of the end node or station.
<macaddr> - The MAC address corresponding to the IP address above.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create a static ARP entry for the IP address 10.48.74.121 and MAC address 00-50-BA-00-07-
36:
DGS-3120-24TC:admin# create arpentry 10.48.74.121 00-50-BA-00-07-36
Command: create arpentry 10.48.74.121 00-50-BA-00-07-36
Success.
DGS-3120-24TC:admin#
8-2 delete arpentry
Description
This command is used to delete an ARP entry, by specifying either the IP address of the entry or
all. Specify ‘all’ clears the Switch’s ARP table.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
