D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
386
Chapter 35 Ethernet Ring Protection
Switching (ERPS) Command
List (RI and EI Mode Only)
enable erps
disable erps
create erps raps_vlan <vlanid 1-4094>
delete erps raps_vlan <vlanid 1-4094>
config erps raps_vlan <vlanid 1-4094> [state [enable | disable] | ring_mel <value 0-7> | ring_port
[west [<port> | virtual_channel] | east [<port> | virtual_channel]] | rpl_port [west | east | none] |
rpl_owner [enable | disable] | protected_vlan [add | delete] vlanid <vidlist> | sub_ring
raps_vlan <vlanid 1-4094> tc_propagation state [enable | disable] | [add | delete] sub_ring
raps_vlan <vlanid 1-4094> | revertive [enable| disable] | timer { holdoff_time <millisecond 0 -
10000> | guard_time <millisecond 10 - 2000 > | wtr_time <min 1 - 12>}]
config erps log [enable | disable]
config erps trap [enable | disable]
show erps {raps_vlan <vlanid 1-4094> {sub_ring}}
35-1 enable erps
Description
This command is used to enable the global ERPS function on a switch. When both the global state
and the specified ring ERPS state are enabled, the specified ring will be activated.
The global ERPS function cannot be enabled, when any ERPS ring on the device is enabled and
the integrity of any ring parameter is not available. For each ring with the ring state enabled when
ERPS is enabled, the following integrity will be checked:
1. R-APS VLAN is created.
2. The Ring port is a tagged member port of the R-APS VLAN.
3. The RPL port is specified if the RPL owner is enabled.
4. The RPL port is not sepcified as virtual channel.
NOTE: EEE and ERPS are mutually exclusive functions.
Format
enable erps
Parameters
None.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
