D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1063
Chapter 116 Virtual Router Redundancy
Protocol (VRRP) Command
List (RI Mode Only)
enable vrrp {ping}
disable vrrp {ping}
create vrrp vrid <vrid 1-255> ipif <ipif_name 12> ipaddress <ipaddr> {state [enable | disable] |
priority <int 1-254> | advertisement_interval <int 1-255> | preempt [true | false] | critical_ip
<ipaddr> | critical_ip_state [enable | disable]}
config vrrp vrid <vrid 1-255> ipif <ipif_name 12> {state [enable | disable] | priority <int 1-254> |
ipaddress <ipaddr> | advertisement_interval <int 1-255> | preempt [true | false] | critical_ip
<ipaddr> | critical_ip_state [enable | disable]}
config vrrp ipif <ipif_name 12> [authtype [none | simple authdata <string 8> | ip authdata <string
16>]]
delete vrrp {vrid <vrid 1-255> ipif <ipif_name 12>}
show vrrp {ipif <ipif_name 12> {vrid <vrid 1-255>}}
config vrrp trap state [enable | disable]
116-1 enable vrrp
Description
This command is used to enable VRRP globally.
Format
enable vrrp {ping}
Parameters
ping - (Optional) Specify that the ping option will be enabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable VRRP:
DGS-3120-24TC:admin#enable vrrp
Command: enable vrrp
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
