D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1141
Appendix D RADIUS Attributes
Assignment
The RADIUS Attributes Assignment on the Switch is used in the following modules: 802.1X (Port-
based and Host-based), MAC-based Access Control, Web-based Access Control (WAC) and
Japanese Web-based Access Control (JWAC).
The description that follows explains the following RADIUS Attributes Assignment types:
• Ingress/Egress Bandwidth
• 802.1p Default Priority
• VLAN
• ACL
To assign Ingress/Egress bandwidth by RADIUS Server, the proper parameters should be
configured on the RADIUS Server. The tables below show the parameters for bandwidth.
The parameters of the Vendor-Specific attributes are:
Vendor-Specific Attribute Description Value Usage
Vendor-ID Defines the vendor. 171 (DLINK) Required
Vendor-Type Defines the attribute. 2 (for ingress bandwidth)
3 (for egress bandwidth)
Required
Attribute-Specific Field
Used to assign the bandwidth
of a port.
Unit (Kbits) Required
If the user has configured the bandwidth attribute of the RADIUS server (for example, ingress
bandwidth 1000Kbps) and the 802.1X authentication is successful, the device will assign the
bandwidth (according to the RADIUS server) to the port. However, if the user does not configure
the bandwidth attribute and authenticates successfully, the device will not assign any bandwidth to
the port. If the bandwidth attribute is configured on the RADIUS server as "0", the effective
bandwidth will be set "no_limited", and if the bandwidth is configured lower than 0 or higher than
maximum supported value, the bandwidth will be ignored.
To assign 802.1p default priority by RADIUS Server, the proper parameters should be
configured on the RADIUS Server. The tables below show the parameters for 802.1p default
priority.
The parameters of the Vendor-Specific attributes are:
Vendor-Specific Attribute Description Value Usage
Vendor-ID Defines the vendor. 171 (DLINK) Required
Vendor-Type Defines the attribute. 4 Required

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
