xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1142
Attribute-Specific Field Used to assign the 802.1p default
priority of the port.
0-7 Required
If the user has configured the 802.1p priority attribute of the RADIUS server (for example, priority 7)
and the 802.1X, or Host-based authentication is successful, the device will assign the 802.1p
default priority (according to the RADIUS server) to the port. However, if the user does not
configure the priority attribute and authenticates successfully, the device will not assign a priority to
this port. If the priority attribute is configured on the RADIUS server is a value out of range (>7), it
will not be set to the device.
To assign VLAN by RADIUS Server, the proper parameters should be configured on the RADIUS
Server. To use VLAN assignment, RFC3580 defines the following tunnel attributes in RADIUS
packets.
The table below shows the parameters for a VLAN:
RADIUS Tunnel
Attribute
Description Value Usage
Tunnel-Type This attribute indicates the tunneling protocol(s)
to be used (in the case of a tunnel initiator) or
the tunneling protocol in use (in the case of a
tunnel terminatior).
13 (VLAN) Required
Tunnel-Medium-Type This attribute indicates the transport medium
being used.
6 (802) Required
Tunnel-Private-
Group-ID
This attribute indicates group ID for a particular
tunneled session.
A string (VID) Required
A summary of the Tunnel-Private-Group-ID Attribute format is shown below.
0 1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Type | Length | Tag | String...
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
The table below shows the definition of Tag field (different with RFC 2868):
Tag field value String field format Note
0x01 VLAN name (ASCII) A tag field of greater than 0x1F is
interpreted as the first octet of the
0x02 VLAN ID (ASCII)
