D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
670
Chapter 66 Multicast VLAN Command
List
create [igmp_snooping | mld_snooping] multicast_vlan <vlan_name 32> <vlanid 2-4094>
{remap_priority [<value 0-7> | none] {replace_priority}}
config igmp_snooping multicast_vlan <vlan_name 32> {[add | delete] [member_port <portlist> |
[source_port <portlist> | untag_source_port <portlist>] | tag_member_port <portlist>] | state
[enable | disable] | replace_source_ip [<ipaddr> | none] | remap_priority [<value 0-7> | none]
{ replace_priority} | cvid [<vlanid 1-4094> | null]}(1)
config mld_snooping multicast_vlan <vlan_name 32> {[add | delete] [member_port <portlist> |
[source_port <portlist> | untag_source_port <portlist>] | tag_member_port <portlist>] | state
[enable | disable] | replace_source_ipv6 [<ipv6addr> | none] | remap_priority [<value 0-7> |
none] {replace_priority} | cvid [<vlanid 1-4094> | null]}(1)
create [igmp_snooping | mld_snooping] multicast_vlan_group_profile <profile_name 1-32>
config igmp_snooping multicast_vlan_group_profile <profile_name 1-32> [add | delete]
<mcast_address_list>
config mld_snooping multicast_vlan_group_profile <profile_name 1-32> [add | delete]
<mcast_v6address_list>
delete [igmp_snooping | mld_snooping] multicast_vlan_group_profile [profile_name
<profile_name 1-32> | all]
show [igmp_snooping | mld_snooping ] multicast_vlan_group_profile {< profile_name 1-32>}
config [igmp_snooping | mld_snooping] multicast_vlan_group <vlan_name 32> [add | delete]
profile_name <profile_name 1-32>
show [igmp_snooping | mld_snooping] multicast_vlan_group {<vlan_name 32>}
delete [igmp_snooping | mld_snooping] multicast_vlan <vlan_name 32>
enable [igmp_snooping | mld_snooping] multicast_vlan
disable [igmp_snooping | mld_snooping] multicast_vlan
config [igmp_snooping | mld_snooping] multicast_vlan forward_unmatched [enable |
disable]
show [igmp_snooping | mld_snooping] multicast_vlan {<vlan_name 32>}
66-1 create [igmp_snooping | mld_snooping] multicast_vlan
Description
This command is used to create a multicast VLAN and implements relevant parameters as
specified. More than one multicast VLANs can be configured.
Newly created IGMP snooping multicast VLANs must use a unique VLAN ID and name, i.e. they
cannot use the VLAN ID or name of any existing 802.1q VLAN.
Also keep in mind the following conditions:
• Multicast VLANs cannot be configured or displayed using 802.1Q VLAN commands.
• An IP interface cannot be bound to a multicast VLAN.
• The multicast VLAN snooping function co-exists with the 802.1q VLAN snooping function.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
