xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

669

DGS-3120-24TC:admin#show cpu_filter l3_control_pkt ports 1:1-1:2

Command: show cpu_filter l3_control_pkt ports 1:1-1:2

Port IGMP Query DVMRP PIM

---- ---------- -------- --------

1:1 Disabled Enabled Disabled

1:2 Disabled Enabled Disabled

DGS-3120-24TC:admin#
