xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
836
maximum limit in Kbits/sec. The actual bandwidth will be an adjusted value based on the
user specified bandwidth. The actual limit may be equal to the user specified limit, but will
not exceed it.. The actual limit recognized by the device, will be displayed when the
command is executed.
<value 8-10240000> - Enter the transmitting data rate here. This value must be between 8
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the port bandwidth:
DGS-3120-24TC:admin#config bandwidth_control 1:1-1:10 tx_rate 100
Command: config bandwidth_control 1:1-1:10 tx_rate 100
Granularity: RX: 8, TX: 8. Actual Rate: TX: 96.
Success.
84-2 show bandwidth_control
Description
This command is used to display the port bandwidth configurations.
The bandwidth can also be assigned by the RADIUS server through the authentication process. If
RADIUS server has assigned the bandwidth, then the RADIUS-assigned bandwidth will be the
effective bandwidth. The authentication with the RADIUS sever can be per port or per user. For
per-user authentication, there may be multiple bandwidth control values assigned when there are
multiple users attached to this specific port. In this case, the largest assigned bandwidth value will
be applied to the effective bandwidth for this specific port. Note that only devices that support
MAC-based VLAN can provide per user authentication.
Format
show bandwidth_contr
ol {<portl
ist>}
Parameters
<portlist> - (Optional) Specify a range of ports to be displayed.
If no parameter specified, system will display all ports bandwidth configurations.
