DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

826

DGS-3120-24TC:admin# show port dot1v ports 1:1

Command: show port dot1v ports 1:1

Port: 1:1

Protocol Group ID VLAN Name Protocol Priority

------------------- --------------------------------- -----------------

1 default -

2 VLAN2 -

3 VLAN3 -

4 VLAN4 -

Success.

DGS-3120-24TC:admin#
