D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1075
117-5 show vlan_counter statistics
Description
This command is used to display the VLAN level traffic statistics.
Format
show vlan_counter statistics {[vlan <vlan_name> | vlanid <vidlist>] {ports <portlist>}} {[rx |
tx]}
Parameters
vlan - (Optional) Specify the VLAN name that will be used for this display.
<vlan_name> - Enter the VLAN name that will be used for this display.
vlanid - (Optional) Specify the VLAN ID that will be used for this display.
<vidlist> - Enter the VLAN ID that will be used for this display.
ports - (Optional) Specify the list of ports that will be used for this display.
<portlist> - Enter the list of ports that will be used for this display.
all - Specify that all ports will be used for this display.
rx - (Optional) Specify that the statistics to be displayed is counted on ingress traffic.
tx - (Optional) Specify that the statistics to be displayed is counted on egress traffic.
Restrictions
None.
Example
To display the VLAN counter statistics:
DGS-3120-24TC:admin#show vlan_counter statistics
Command: show vlan_counter statistics
VLAN Port Frame Type Frames/Bytes Frames/Bytes Per Sec
---- ---- -------------------- ---------------------- ---------------------
-
1 3 RX Broadcast(Packet) 0 0
2 3 RX Multicast(Packet) 0 0
1 3 TX Broadcast(Packet) 0 0
4 5 TX Unicast(Packet) 0 0
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
