D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1078
Parameters
<portlist> - Enter a list of ports used for the configuration here.
all - Specify that all the ports will be used for this configuration.
state - Specify that the port is a VLAN trunk port or not.
enable - Specify that the port is a VLAN trunk port.
disable - Specify that the port is not a VLAN trunk port.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To configure VLAN trunk ports:
DGS-3120-24TC:admin# config vlan_trunk ports 1:1-1:5 state enable
Command: config vlan_trunk ports 1:1-1:5 state enable
Success.
DGS-3120-24TC:admin#
Port 6 is LA-1 member port; port 7 is LA-2 master port:
DGS-3120-24PC:admin#config vlan_trunk ports 1:6-1:7 state enable
Command: config vlan_trunk ports 1:6-1:7 state enable
Success.
DGS-3120-24PC:admin#config vlan_trunk ports 1:7 state disable
Command: config vlan_trunk ports 1:7 state disable
Success.
DGS-3120-24PC:admin#config vlan_trunk ports 1:6-1:7 state disable
Command: config vlan_trunk ports 1:6-1:7 state disable
Success.
DGS-3120-24PC:admin#
Port 6 is LA-1 member port; port 7 is LA-1 master port:
DGS-3120-24TC:admin# config vlan_trunk ports 1:6-1:7 state enable
Command: config vlan_trunk ports 1:6-1:7 state enable
Success.
DGS-3120-24TC:admin#
Port 6, 7 have different VLAN configurations before enabling VLAN trunk.
Port 6 is LA-1 member port; port 7 is LA-1 master port.
