D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
105
<netmask> - Enter the destination IP address mask here.
dscp - (Optional) Specify the DSCP mask.
icmp - (Optional) Specify that the rule applies to ICMP traffic.
type - (Optional) Specify the type of ICMP traffic.
code - (Optional) Specify the code of ICMP traffic
igmp - (Optional) Specify that the rule applies to IGMP traffic.
type - (Optional) Specify the type of IGMP traffic.
tcp - (Optional) Specify that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask here.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask here.
flag_mask - (Optional) Specify the TCP flag field mask.
all – Specify that all the flags will be used for the TCP mask.
urg – (Optional) Specify that the TCP flag field will be set to ‘urg’.
ack - (Optional) Specify that the TCP flag field will be set to ‘ack’.
psh - (Optional) Specify that the TCP flag field will be set to ‘psh’.
rst - (Optional) Specify that the TCP flag field will be set to ‘rst’.
syn - (Optional) Specify that the TCP flag field will be set to ‘syn’.
fin - (Optional) Specify that the TCP flag field will be set to ‘fin’.
udp - (Optional) Specify that the rule applies to UDP traffic.
src_port_mask - Specify the UDP source port mask.
<hex 0x0-0xffff> - Enter the UDP source port mask here.
dst_port_mask - Specify the UDP destination port mask.
<hex 0x0-0xffff> - Enter the UDP destination port mask here.
protocol_id_mask - (Optional) Specify that the rule applies to IP protocol ID traffic.
<0x0-0xff> - Enter the protocol ID mask here.
user_define_mask - (Optional) Specify that the rule applies to the IP protocol ID, and that
the mask option behind the IP header length is 20 bytes.
<hex 0x0-0xffffffff> - Enter a user-defined mask value here.
packet_content_mask - Specify the packet content mask. Only one packet_content_mask
profile can be created.
offset_chunk_1 - (Optional) Specify that the offset chunk 1 will be used.
<value 0-31> - Enter the offset chunk 1 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 1 mask here.
offset_chunk_2 - (Optional) Specify that the offset chunk 2 will be used.
<value 0-31> - Enter the offset chunk 2 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 2 mask here.
offset_chunk_3 - (Optional) Specify that the offset chunk 3 will be used.
<value 0-31> - Enter the offset chunk 3 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 3 mask here.
offset_chunk_4 - (Optional) Specify that the offset chunk 4 will be used.
<value 0-31> - Enter the offset chunk 4 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 4 mask here.
ipv6 - Specify this is the IPv6 mask.
class - (Optional) Specify the IPv6 class.
flowlabel - (Optional) Specify the IPv6 flow label.
source_ipv6_mask - (Optional) Specify an IPv6 source sub-mask.
<ipv6mask> - Enter the source IPv6 mask value here.
destination_ipv6_mask - (Optional) Specify an IPv6 destination sub-mask.
<ipv6mask> -Enter the destination IPv6 mask value here.
tcp - (Optional) Specify that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify an IPv6 Layer 4 TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask value here.
des_port_mask - (Optional) Specify an IPv6 Layer 4 TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask value here.
udp - (Optional) Specify that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the UDP source port mask.
<hex 0x0-0xffff> - Enter the UDP source port mask value here.
dst_port_mask - (Optional) Specify the UDP destination port mask.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
