xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
108
0-7>] | counter [enable | disable]} | mirror {group_id <value 1-4>} | deny] {time_range
<range_name 32>} | delete access_id <value 1-256>]
Parameters
profile_id - Specify the index of the access list profile.
<value 1-6> - Enter the profile ID value here. This value must be between 1 and 6. A lower
value denotes a higher priority.
profile_name - Specify the name of the profile.
<name 1-32> - Enter the profile name here. This name can be up to 32 characters long.
add access_id - Specify to add the access ID. The value is from 1 to 256, but the supported
maximum number of entries depends on the project. If the auto_assign option is selected, the
access ID is automatically assigned, when adding multiple ports.
auto_assign - Specify that the access ID will automatically be assigned.
<value 1-256> - Enter the access ID used here. This value must be between 1 and 256. A
lower value denotes a higher priority.
ethernet - Specify to configure the ethernet access profile.
vlan - (Optional) Specify the VLAN name.
<vlan_name 32> - Enter the name of the VLAN here. This name can be up to 32
characters long.
vlan_id - (Optional) Specify the VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
mask - (Optional) Specify an additional mask parameter that can be configured.
<hex 0x0-0x0fff> - Enter the mask value here.
source_mac - (Optional) Specify the source MAC address.
<macaddr> - Enter the source MAC address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<macmask> - Enter the source MAC mask used here.
destination_mac - (Optional) Specify the destination MAC address.
<macaddr> - Enter the destination MAC address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<macmask> - Enter the destination MAC mask here.
802.1p - (Optional) Specify the value of the 802.1p priority tag. The priority tag ranges from 1
to 7.
<value 0-7> - Enter the 802.1p priority tag value here.
ethernet_type - (Optional) Specify the Ethernet type.
<hex 0x0-0xffff> - Enter the Ethernet type mask here.
ip - Specify to configure the IP access profile.
vlan - (Optional) Specify a VLAN name.
<vlan_name 32> - Enter the name of the VLAN here. This name can be up to 32
characters long.
vlan_id - (Optional) Specify that VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
mask - (Optional) Specify an additional mask parameter that can be configured.
<hex 0x0-0x0fff> - Enter the mask value here.
source_ip - (Optional) Specify an IP source address.
<ipaddr> - Enter the source IP address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<netmask> - Enter the source netmask used here.
destination_ip - (Optional) Specify an IP destination address.
<ipaddr> - Enter the destination IP address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<netmask> - Enter the destination netmask used here.
dscp - (Optional) Specify the value of DSCP. The DSCP value ranges from 0 to 63.
<value> - Enter the DSCP value here.
icmp - (Optional) Specify to configure the ICMP parameters.
type - (Optional) Specify that the rule will apply to the ICMP Type traffic value.
<value 0-255> - Enter the ICMP type traffic value here. This value must be between 0
