D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
114
==============================================================================
DGS-3120-24TC:admin#
The following example displays an access profile that supports an entry mask for each rule:
DGS-3120-24TC:admin# show access_profile profile_id 2
Command: show access_profile profile_id 2
Access Profile Table
Profile ID: 2 Profile Name: 2 Type : Ethernet
Mask on
VLAN : 0xF
Source MAC : FF-FF-FF-00-00-00
Destination MAC : 00-00-00-FF-FF-FF
Available HW Entries: 255
-------------------------------------------------------------------------------
-
Rule ID : 22 Ports: 1-7
Match on
VLAN ID : 8 Mask : 0xFFF
Source MAC : 00-01-02-03-04-05 Mask : FF-FF-FF-FF-FF-FF
Destination MAC :00-05-04-03-02-00 Mask : FF-FF-FF-FF-FF-00
Action:
Deny
DGS-3120-24TC:admin#
The following example displays the packet content mask profile for the profile with an ID of 5:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
