D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
117
optional parameter. The default value is 4*1024.
<value 0-131072> - Enter the peak burst size value here. This value must be between 0
and 131072.
color_blind - (Optional) Specify the meter mode as color-blind. The default is color-blind
mode.
color_aware - (Optional) Specify the meter mode as color-aware. The final color of the packet
is determined by the initial color of the packet and the metering result.
conform - (Optional) Specify the action when a packet is mapped to the “green” color.
permit - Permits the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter option will be enabled.
disable - Specify that the ACL counter option will be disabled.
exceed - Specify the action when a packet is mapped to the “yellow” color.
permit - Permits the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter option will be enabled.
disable - Specify that the ACL counter option will be disabled.
violate - Specify the action when a packet is mapped to the “red” color.
permit - Permits the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter option will disable - Specify that the ACL counter
option will be disabled.be enabled.
sr_tcm - Specify “single rate three color mode”.
cir - Specify the ommitted Information Rate. The unit is Kbps.
<value 0-1048576> - Enter the comitted information rate value here. This value must be
between 0 and 1048576.
cbs - Specify the “Committed Burst Size” The unit is Kbytes.
<value 0-131072> - Enter the commited burst size value here. This value must be between
0 and 131072.
ebs - Specify the “Excess Burst Size”. The unit is Kbytes.
<value 0-131072> - Enter the excess burst size value here. This value must be between 0
and 131072.
color_blind - (Optional) Specify the meter mode as color-blind. The default is color-blind
mode.
color_aware - (Optional) Specify the meter mode as color-aware. The final color of the packet
is determined by the initial color of the packet and the metering result.
conform - (Optional) Specify the action when a packet is mapped to the “green” color.
permit - Permits the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
