xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

Format

Parameters

None.

Restrictions

None.

Example

To login the Switch with a user name dlink:

DGS-3120-24TC:admin# login

Command: login

UserName:dlink

PassWord:****

DGS-3120-24TC:admin#

2-7 logout

Description

This command is used to logout the facility.

Format

logout

Parameters

None.

Restrictions

None.

Example

To logout current user:
