D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
230
characters long.
md_index - Specify the maintenance domain index.
<uint 1-4294967295> - Enter the maintenance domain index value here. This value must
between 1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name here. This name can be up to 22
characters long.
ma_index - Specify the maintenance association index.
<uint 1-4294967295> - Enter the maintenance association index value here. This value
must between 1 and 4294967295.
mepid - The MEP ID in the MD which sends LCK frame.
<int 1-8191> - Enter the MEP ID value here. This value must be between 1 and 8191.
period - (Optional) The transmitting interval of LCK PDU. The default period is 1 second.
1sec - Specify that the transmitting interval will be set to 1 second.
1min - Specify that the transmitting interval will be set to 1 minute.
level - (Optional) The client level ID to which the MEP sends LCK PDU. The default client MD
level is MD level at which the most immediate client layer MIPs and MEPs exist.
<int 0-7> - Enter the client level ID here. This value must be between 0 and 7.
state - (Optional) Specify to enable or disable the LCK function.
enable - Specify that the LCK function will be enabled.
disable - Specify that the LCK function will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the LCK function enabled and client level is 5:
DGS-3120-24TC:admin# config cfm lock md op-domain ma op-ma mepid 1 state enable
level 5
Command: config cfm lock md op-domain ma op-ma mepid 1 state enable level 5
Success.
DGS-3120-24TC:admin#
20-3 cfm lock md
Description
This command is used to start/stop cfm management lock. This command will result in the MEP
sends a LCK PDU to client level MEP.
Format
cfm lock md [<string 22> | md_index <uint 1-4294967295>] ma [<string 22> | ma_index <uint
1-4294967295>] mepid <int 1-8191> remote_mepid <int 1-8191> action [start | stop]
Parameters
<string 22> - Enter the maintenance domain name here. This name can be up to 22 characters
long.
md_index - Specify the maintenance domain index.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
