xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

293

Restrictions

None.

Example

To display local dhcp relay status:

DGS-3120-24TC:admin# show dhcp_local_relay

Command: show dhcp_local_relay

DHCP/BOOTP Local Relay Status : Disabled

DHCP/BOOTP Local Relay VID List : 1,3-4

DGS-3120-24TC:admin#
