DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

498

DGS-3120-24TC:admin#show route_map

Command: show route_map

route_map : map1

--------------------------

sequence : 10 (Permit)

Match clauses:

Set clauses:

-----------------

sequence : 20 (Permit)

Match clauses:

Set clauses:

Total Route Map Count:1

DGS-3120-24TC:admin#
