D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
46
Example
To configure the port capability:
DGS-3120-24TC:admin# config 802.1x capability ports 1:1-1:10 authenticator
Command: config 802.1x capability ports 1:1-1:10 authenticator
Success.
DGS-3120-24TC:admin#
4-12 config 802.1x max_users
Description
This command is used to limit the maximum number of users that can be learned via 802.1X
authentication. In addition to the global limitation, maximum user for per port is also limited. It is
specified by config 802.1x auth_parameter command.
Format
config 802.1x max_users [<value 1–448> | no_limit]
Parameters
<value 1-448> - Enter the maximum number of users. This value must be between 1 and 448.
no_limit – Specify that the maximum user limit will be set to 448.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure 802.1X number of users to be limited to 200:
DGS-3120-24TC:admin#config 802.1x max_users 200
Command: config 802.1x max_users 200
Success.
DGS-3120-24TC:admin#
4-13 config 802.1x auth_parameter
Description
This command is used to configure the parameters that control the operation of the authenticator
associated with a port.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
